Nneɛma a Wɔyɛ no Ho Nsɛm
Model a 4.3-10 male rf connector yɛ 4310-J3/8S.4.3-10 connectors de ade koro no ara, robust design sɛ 7-16 connectors nanso ɛyɛ nketewa na ɛkɔ 40% lighter, ma kwan ma pii dense, lighter weight applications. Saa nhyehyeɛ yi ne IP67 hyia berɛ a wɔde abɔ mu de abɔ ho ban afiri mfuturo ne nsuo a ɛbɛkɔ mu ama abɔnten dwumadie, na ɛma VSWR adwumayɛ a ɛkyɛn so kɔsi 6 GHz. Ɛlektrik ne mfiri afã horow a ɛtetew mu ma PIM adwumayɛ a ɛyɛ den yiye a coupling torque mfa ho, na ɛma ɛyɛ mmerɛw sɛ wɔde besisi hɔ.
Electrical ho adwuma
|
Impedance a ɛyɛ den |
50Ω |
|
Frequency Range a Wɔde Di Dwuma |
0-3GHz na ɛwɔ hɔ |
|
Adwumayɛ Voltage |
2700V |
|
VSWR |
Ennu anaasɛ ɛne 1.15@3GHz yɛ pɛ |
|
Insulation a Ɛko Tia |
Ɛboro anaasɛ ɛne 10000mΩ yɛ pɛ |
|
Voltage a wotumi gyina ano |
4000V |
|
Mfinimfini Nkitahodi a Ɛko Tia(mΩ) . |
Ennu anaasɛ ɛne 0.4 yɛ pɛ |
|
Abɔnten so Nkitahodi a Ɛko Tia(mΩ) . |
Ennu anaasɛ ɛne 1.5 yɛ pɛ |
|
RF leakage Nneɛma a ɛyɛ adwuma yiye |
Ɛboro anaasɛ ɛne 125dB@3GHz yɛ pɛ |
|
Sɛnea ɛtra hɔ kyɛ |
500 a ɛyɛ kyinhyia |
Nneɛma ne Plating
| 4310-J3/8S |
Atadeɛ |
Plating a wɔde yɛ nneɛma |
|
Nipadua |
Kɔbere a wɔde yɛ |
CuSnZn |
|
Mfinimfini kwankyerɛfo |
Kɔbere a wɔde yɛ |
Ag |
|
Couping nut a wɔde yɛ adwuma |
Kɔbere a wɔde yɛ |
CuSnZn |
|
O-ring Nsɔano |
Silicone Rɔba a Wɔde Yɛ Adwuma |
|
|
Insulator a wɔde siw mframa ano |
PTFE na ɛyɛ |
Nneɛma a atwa yɛn ho ahyia
|
Ɔhyew a Ɛwɔ Hɔ |
-65 digrii ~ +165 digrii |
|
Nsuframa |
＜95％ |
|
Nkyene-fog Sɔhwɛ |
48h |
|
Nsuo ntumi nkɔ mu |
IP67 |
Nea Ɛma Ɛyɛ Titiriw?
4.3-10 coaxial connector no da nsonsonoeɛ titire pii adi wɔ coaxial connectors a atwam no ho, a design features a wɔanhunu wɔ 4.1/9.5 connector a ne kɛseɛ te sɛ no mu ka ho. Ebia ade a ɛho hia sen biara wɔ 4.3-10 coaxial connector no mu ne mpaapaemu a ɛda anyinam ahoɔden ne mfiri aware ntam, a ɛma connector no tumi kura transmission ne PIM adwumayɛ a eye sen biara mu mpo bere a wɔanhyɛ no den koraa no. Bio nso, esiane sɛ anyinam ahoɔden nkitahodi ne mating surface a ɛwɔ 4.3-10 coaxial connector no so no, connector no akyi nhyehyɛe no bɔ ho ban nti, ɛfata kɛse ma field installation. Bio nso, kɛseyɛ yɛ ade titiriw. 4.3-10 nkitahodi no, ne ne flange a wɔde si so no, hyɛ baabi a ɛyɛ nsateakwaa 1 ahinanan (sentimita ahinanan 6.45). Saa nneɛma yi ma 4.3-10 connector no yɛ nea eye kyɛn so a wɔpaw ma nhyehyɛe foforo ne retrofits nyinaa.
Zhenjiang Tongda Electronics Co., Ltd. yɛ adwumayɛfo a wɔyɛ 4.3-10 mmarima rf nkitahodi, a ɛma wo nneɛma a ɛfata wo.
